Canon CR-N5OO

R 122,075.00
Auto Tracking Option
Minus Plus

Canon CR-N5OO - without Auto Tracking is backordered and will ship as soon as it is back in stock.

Description

Canon CR-N5OO

Overview:

A dynamic PTZ camera aimed at productions and video streaming, the CR-N500 boasts a 1.0-type 4K UHD sensor and Dual Pixel CMOS AF, plus 15x optical zoom, smooth pan and tilt as well as image stabilisation to capture content in superb detail and the ability to automate your productions using Auto Tracking* and Auto Loop functions

Specifications in detail

Camera

  • Image Sensor
    Type 1.0 (1.0 in.) single-plate CMOS sensor
  • Effective Pixels
    approx. 8.29 megapixels (3840 x 2160)
  • Lens
    f=8.3 – 124.5 mm, F/2.8 – 4.5, 15x optical zoom, 9-bladed iris diaphragm
  • Optical Zoom
    15x optical zoom
  • Digital Zoom
    20x digital zoom
  • Focal Length
    f=8.3 – 124.5 mm, F/2.8 – 4.5,
    35mm equivalent focal length: approx. 25.5 (W) – 382.5 mm (T)
  • Angle of View
    Horizontal: 73.0 (W) – 5.7° (T)
    Vertical: 45.2° (W) – 3.2° (T)
  • Minimum Subject Illumination
    3840 x 2160: Approx. 1.5 lux (shutter speed 1/30 sec., Frame Rate 29.97P, Gain 33.0 dB)
    1920 x 1080: Approx. 3 lux (shutter speed 1/60 sec., Frame Rate 59.94P, Gain 33.0 dB)
  • Shutter Speed
    1/3 – 1/2000 sec. (specific values depend on the frame frequency and frame rate)
  • Iris
    Manual/Automatic aperture
  • Gain
    -6.0 db ～ 33.0 db
  • ND Filter
    Built-in (Off, 1/4, 1/16, 1/64), motor operated
  • White Balance
    AUTO (AWB), Set A, Set B, preset settings (daylight: 5,600 K*, tungsten lamp: 3,200 K*),
    color temperature setting (2,000 K – 15,000 K), Manual

    * Color temperatures are given for reference purposes only.
  • Focus
    Focus mode: Manual, AF-boosted MF, Continuous AF, Face AF, Tracking
    AF type: Dual Pixel CMOS AF, Contrast AF
  • Gamma
    Normal1 (Standard), Normal2 (x4.0), Normal3 (BT.709), Normal4 (x5.0), Wide DR, Canon Log 3
  • Pan and Tilt
    Pan operation range: Horizontal ±170°
    Pan operation speed: 0.1° – 100°/sec.
    Tilt operation range: Vertical -30° – +90°
    Tilt operation speed: 0.1° – 100°/sec.

Pan and Tilt Operation

  • Protocol
    XC (Canon's original), RTSP/RTP, NDI|HX, RTMP/RTMPS, Standard Communication (Serial), Standard Communication (IP), SRT, FreeD

Server

  • Video Output Format: SDI
    1920 x 1080: 59.94P/59.94i, 50.00P/50.00i/25.00P, 29.97P/23.98P (4:2:2 10 bit)
    1280 x 720: 59.94P, 50.00P (4:2:2 10 bit)
    – Same video format required for SDI and HDMI (cannot select different formats for
    SDI and HDMI)
    – When 3840 x 2160 is selected for HDMI, video will not be outputted to SDI.
  • Video Output Format: HDMI
    3840 x 2160: 29.97P, 25.00P, 23.98P (4:2:2 10 bit)
    1920 x 1080: 59.94P/59.94i, 50.00P/50.00i/25.00P, 29.97P/23.98P (4:2:2 10 bit)
    1280 x 720: 59.94P, 50.00P (4:2:2 10 bit)
    – Same video format required for SDI and HDMI (cannot select different formats for
    SDI and HDMI)
    – When 3840 x 2160 is selected for HDMI, video will not be outputted to SDI.
  • Video Output Format: IP
    3840 x 2160: 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    1920 x 1080: 59.94 fps, 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    1280 x 720: 59.94 fps, 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    640 x 360: 59.94 fps, 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    – If 59.94/50.00 Hz is selected for the frame frequency, the 3840 x 2160 format cannot be selected.
    – A frame rate that exceeds the frame frequency cannot be selected.
    – JPEG has one pattern fixed depending on the frame frequency (format is fixed and cannot be selected)
    Resolution: 1280 x 720
    When frame frequency is 59.94/50.00 Hz: 14.99 fps, when frame frequency is 23.98 Hz: 11.99 fps, when frame frequency is 29.97/25.00 Hz: 12.50 fps
  • Video Output Format: USB
    -
  • Preset
    Number of presets: Max. 100 (including home position)

Interface

  • Communication Control
    LAN, Wi-Fi, Serial, IR
  • Network Terminal
    LAN x 1, RJ45, 1000Base-T
  • SDI OUT Terminal
    BNC jack (output only) x 1, 0.8 Vp-p/75 Ω, unbalanced
    SMPTE 424, SMPTE 425, SMPTE ST 299-2 compliant
    Embedded audio, Time code (VITC/LTC)
  • GEN-LOCK Terminal
    BNC jack x 1, 1.0 Vp-p/75 Ω, input only
  • HDMI OUT Terminal
    HDMI connector x 1, output only
  • RS-422 Terminal
    RJ45 connector x 1
  • INPUT 1/INPUT 2 Terminals
    XLR/Audio Input (3-pin jack) (pin1: shield, pin2: hot, pin3: cold), 2 sets, balanced
    Sensitivity (MIC): -60 dBu (Manual volume center, full scale -18 dB)/600 Ω/Att.: 20 dB
    Sensitivity (LINE): +4 dBu (Manual volume center, full scale -18 dB)/1 kΩ or more
    Supply Voltage: 48 V DC (Bias resistance: 6.8 kΩ)
  • MIC Terminal
    ϕ3.5 mm stereo mini jack (unbalanced, plug-in power supported)
    Sensitivity (MIC): -72 dBV (Manual volume center, full scale -18 dB)/1 kΩ or more/Att.: 20 dB
    Sensitivity (LINE): -10 dBV (Manual volume center, full scale -18 dB)/1 kΩ or more
    Supply Voltage: 2.4 V DC (Bias resistance: 2.2 kΩ)
  • USB Terminal
    Type-A (USB 2.0) x 1 (future expansion)

Physical Features

  • Operating Environment
    Temperature
    0°C – +40°C (+32°F – +104°F)
    Humidity
    10% – 90% (without condensation)
  • Power Supply
    PoE: PoE+ power supply via LAN connector (IEEE802.3at compliant)
    – PoE cannot be used
    External power source: 24 V DC (using included AC adaptor)
  • Power Consumption
    PoE+ Input: Approx. 19.6 W* max. (body only)
    DC Input: Approx. 18.6 W max. (body only)

    * Class 4 (25.5 W required) for power supply devices
  • Dimensions (W x H x D)
    Approx. 200 x 269 x 208 mm (7.87 x 10.59 x 8.19 in.) (excluding protrusions)
  • Weight
    Approx. 4.1 kg (9.04 lb.) (body only)


*Free Auto Tracking App RA-AT001(Lite) available via new FW, 1.5.0 or later. Paid license is necessary for full functionality of auto tracking
