Overview:
Capture UHD 4K30 resolution video and keep your subjects in frame with AI auto framing using this black X1 Ultra PTZ Camera with 12x Zoom from BirdDog. Boasting a powerful 12x zoom as well as color matrix, API, and Kelvin control, the versatile X1 Ultra offers exceptional low-light performance and support for Wi-Fi 5 and NDI|HX3.
Physical connectivity options include an HDMI output and a USB/UVC output with independent resolution for direct connection to Microsoft Teams, Zoom, and more. A built-in halo tally and a 2.93" E-Ink display augment the camera's broad functionality features, and PoE (Power over Ethernet) support allows you to power the camera using a single Ethernet cable and facilitating quick and easy setup with limited cable clutter.
Specifications:
Imaging
Image Sensor |
1/2.8"-Type CMOS
|
Horizontal Resolution (TV Lines) |
2160 TV Lines
|
Sensor Resolution |
Effective: 8.29 Megapixel (3840 x 2160)
|
IR Cut Filter |
No
|
Built-In ND Filter |
No
|
Focus Control |
Autofocus Manual Focus
|
Exposure Control
Signal-to-Noise Ratio |
50 dB
|
White Balance |
Range: 2500 to 9000K Presets: Manual, VAR
|
Lens
Focal Length |
4.1 to 49.2mm
|
Optical Zoom Ratio |
12x
|
Field of View |
Horizontal: 70.28 to 6.57° Vertical: 42.06 to 3.76° Diagonal: 78.36 to 7.5°
|
Maximum Aperture |
f/1.8 to 2.68
|
Video Capture
External Recording Modes |
HDMI / RJ45 / USB UHD 4K (3840 x 2160) at 25/29.97/30.00 fps HD (1920 x 1080p) at 25/29.97/30.00 fps HD (1280 x 720) at 25/29.97/30.00 fps
|
Embedded Audio |
HDMI/LAN (RJ45)/SDI
|
Broadcast Output |
NTSC/PAL
|
IP Streaming |
NDI|HX2, NDI|HX3, RTMP, RTSP 3840 x 2160 at 30p
|
Control
Presets |
255
|
Move Speed |
Pan: 0.1 to 80°/sec Tilt: 0.1 to 60°/sec
|
Movement Range |
Pan: -175 to 175° Tilt: -90 to 90°
|
Tally Light |
Yes
|
Supported Control Protocols |
ONVIF Profile S RS-232 RS-485
|
Interface
Video I/O |
1x HDMI (Unspecified Signal) Output
|
Other I/O |
1x USB-C 1x RJ45 (NDI)
|
Built-In Speaker |
No
|
Power
PoE Support |
PoE 802.3af
|
Power I/O |
1x RJ45 (12VDC at 2 A) Input
|
Power Consumption |
13 W
|
Environmental
Storage Temperature |
14 to -40°F / -10 to -40°C
|
Operating Humidity |
20 to 80%
|
General
Dimensions (W x H x D) |
10.2 x 8.5 x 7.8" / 260 x 217 x 197 mm
|
Weight |
3.15 lb / 1.43 kg (Body Only)
|
